Extendahoe Dipper Arm Parts

1 - Inner Dipper Stick 2 - Bushing 2 - Bushing 4 - Pin, Dipper Cylinder to Dipper 5 - Pin, Boom to Dipper 6 - Nut, Boom to Dipper Pin 7 - Wear Plate (Extendible Dipper) 7 - Wear Plate (Extendible Dipper) 7 - Wear Plate (Extendible Dipper) 7 - Wear Plate (Extendible Dipper) 12 - Outer Dipper Stick 13 - Pin, Extendahoe Cylinder Tube End
Click on each number to jump to the product page. Each number on the image is a "Ref #" that can be matched on the table below.

Fits Models At A Glance: Dipper Stick at Dipper Cylinder Rod: 580K, 580 Super K, 580M, 580 Super M Boom at Dipper Cylinder Tube: 580K, 580 Super K Steering Axle, Rear Pivot Bushing (2WD): 580K, 580 Super K, 580L, 580 Super L, 580M, 580...

Fits Models At A Glance: Case Backhoes: 580K, 580 Super K, 590 Turbo Fits Backhoes with Buckets wider than 12" Key Points: Connects Dipper stick to backhoe bucket Style with Ear and retaining pin hole Larger of the two bucket pins Diameter: 1-3/4"...

Fits Models At A Glance: Fits Case 590 Turbo Fits Case 590 Super L (Series I - Before Serial Number JJG0210574). Key Points: Part Number: D150963, D144438 Quality Inspection: Thoroughly checked for cracks and wear to ensure reliability. Weight:...

Fits Models At A Glance: Case 590 Super L, 590 Super M with Extendahoe feature. Key Points: Part Details: Used OEM, Part # 294300A1, Casting # 294301A1. Material & Durability: Made of Ductile Iron, weighing 595 lbs. Quality Inspection: Each stick...

Case 590 Super N Backhoe Inner Dipper Stick Fits Models with Ext-a-Hoe Good Used - Low Hour Part # 84298779

Case Backhoe Bushing, Dipper at Boom  Fits Case 590 Super L, 590 Super M

Case Backhoe Pin Fits Case: 590 Super L, 590 Super M Connects the Dipper Cylinder to the Inner Dipper Stick Interchanges with # 175581A1

Fits Models: Case 590 Super L, 590 Super M Key Features: Interchanges with Part Numbers: 87356541, 175313A1 Application: Connects the boom to the dipper stick; suitable for both standard and extendible dipper sticks. Size: 3.15" (80 mm) outside...

Fits Case Models: Application: Lower Swing Tower to Frame Pin: 580D, 580 Super E Application: Boom to Dipper Stick Pin: 580K, 580SK, 580L, 580SL, 580M, 580SM, 580N, 580SN, 590SL, 590SM, 590SN Key Features: Size: 1.75" Nut. Part Numbers:...

Case Backhoe Extendible Dipper Stick Wear Pad Fits Case Backhoes: 580K, 580 Super K, 580L, 580 Super L, 590 Turbo, 590 Super L, 590 Super M Interchanges with Case Part #'s 132716A1 and 363321A1 Four used per machine, Sold Individually

Case Backhoe Outer Dipper Stick (Extendahoe) Fits Case 590 Turbo Used - OEM Low Hour Take Off

Case Backhoe Outer Dipper Stick (Extendible Dipper) Fits Case 590 Super L, 590 Super M OEM Low-Hour Used Fits Models with Standard Manual Coupler Style

Fits Models At A Glance: Case Backhoes: 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 590 Turbo, 590 Super L, 590 Super M, 590 Super N Key Notes: Outside Diameter: 40 mm (1.57 inches) Length: 136 mm (5.35...

Fits Models At A Glance Fits Case Backhoes: 590 Super L, 590 Super M Connects the Backhoe Dipper Stick to the Bucket Cylinder Fits Both Standard and Extendible Dipper Sticks Key Points Replaces Part Number: 175316A1 Dimensions: 60mm Outside Diameter,...

Fits Models At A Glance: Fits Case Backhoes: 580K Phase III (After Serial # JJG0020000) Fits Case Backhoes: 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M Key Points: Fits Models with Standard or...

Fits Models: Case Backhoes: 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 590 Turbo, 590 Super L, 590 Super M Key Features: Designed for 1.5" diameter pins. Replaces Part # D25279...

Fits Models At A Glance: Case 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M Key Features: Specially designed for 1 3/4" diameter pins Replaces Part Numbers: D25280,...

Case Backhoe Snap Ring  Fits 2" Diameter Pins Replaces #: 103-16200, D26919, R19659,468371R1, N7263, S117847 and 800-44050 Fits Case 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580...

Case Washer Fits 1.5" Diameter Pins 10 Gauge 0.140" Thick 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Thick and Sturdy: Case Washer for Heavy-Duty Jobs

Case Backhoe Washer Fits 1.5" Pins 14 Gauge 0.078" Thick Replaces #'s: 495-81292, 195-563, 195-63, D28610 Fits Case 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590...

Fits Models At A Glance: Case Backhoes: 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 590 Turbo, 590 Super L, 590 Super M, 590 Super N Key Notes: Fits 1.75" diameter pins 10 gauge 0...

Case Washer Fits 1.75" Diameter Pins 14 Gauge .078" Thick Fits Case 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc

REF # Image Fits Model Description Part # Price Product Details
(10 & 17-Bucket), (6-Front Axle) D138047 Bushing for Case 580K to 590 Super N See Details 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 590 Turbo, 590 Super L, 590 Super M, 590 Super N, 585G, 586G, 588G, 586H, 588H, 570LXT, 570MXT, 570NXT Bushing (60mm OD) D138047
$24.00
View Info
(8-Bucket), (10-Dipper) Bucket Pin for Case 580K Backhoe See Details 580K, 580 Super K, 590 Turbo Pin, Bucket to Dipper (13"+) D140655
$58.00
View Info
1 Case 590 Turbo Backhoe Inner Dipper Stick Used -- 298077A1 See Details 590 Turbo, 590 Super L Series 1 Inner Dipper Stick (Used) 298077A1-U
$2,095.00
View Info
1 Case Backhoe Used Replacement Inner Dipper Stick for Extendahoe. See Details 590 Super L, 590 Super M Inner Dipper Stick (Used) 294300A1-U
$2,790.00
View Info
1 Case 590 Super N Backhoe Inner Dipper Stick (Ext-a-Hoe)(Used) -- 84298779-U | Broken Tractor See Details 590 Super N Inner Dipper Stick (Used) 84298779-U
$2,385.00
View Info
2 Case Backhoe Bushing, Dipper at Boom 590 Super L, 590 Super M -- D144161 See Details 590 Super L, 590 Super M Bushing D144161
$45.00
View Info
4 Case Backhoe Pin, Dipper Cylinder to Boom 590 Super L, 590 Super M -- 175581A1 See Details 590 Super L, 590 Super M Pin, Dipper Cylinder to Dipper 0 175581A1
$105.00
View Info
5 Case Backhoe Pin, Boom to Dipper 590 Super L, 590 Super M -- 175313A1 See Details 590 Super L, 590 Super M Pin, Boom to Dipper 0 175313A1
$175.00
View Info
6 Case Backhoe Nut, Boom to Dipper Pin 590 Super L, 590 Super M -- 181042A1 See Details 580D*, 580SE*, 580K, 580SK, 580L, 580SL, 580M, 580SM, 580N, 580SN, 590SL, 590SM, 590SN Nut, Boom to Dipper Pin 181042A1
$42.00
View Info
7 Case Backhoe Extendahoe Wear Plate -- 363321A1 | Broken Tractor See Details 580K, 580 Super K, 580L, 580 Super L, 590 Turbo, 590 Super L, 590 Super M Wear Plate (Extendible Dipper) 363321A1
$75.00
View Info
12 Case Backhoe Outer Dipper Stick (Extend-a-Hoe)(Used) -- 108942A1-U | Broken Tractor See Details 590 Turbo Outer Dipper Stick (Used) 108942A1-U
$1,850.00
View Info
12 Case Backhoe Outer Dipper Stick (Extendible Dipper) -- 87335180 | Broken Tractor See Details 590 Super L, 590 Super M Outer Dipper Stick (Used) 87335180-U
$1,950.00
View Info
13 Case 580K Extendahoe Cylinder Pin See Details 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 590 Turbo, 590 Super L, 590 Super M, 590 Super N Pin, Extendahoe Cylinder Tube End 300588A1
$44.00
View Info
13 Dipper-to-Bucket-Cylinder-Pin-for-Case-590-Super-L See Details 590 Super L, 590 Super M Pin, Dipper Stick to Bucket Cylinder 175316A1
$84.00
View Info
Case Backhoe Hydraulic Line Rubber Support Cushion See Details 580K-III, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M Hydraulic Line Support 184297A1
$98.00
View Info
Case Backhoe Snap Ring for 1.5" Diameter Pins See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Snap Ring (1.5" Pins) D25279
$4.50
View Info
Heavy Duty Pin Retainer Snap Ring for Case Backhoes at Broken Tractor See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Snap Ring (1.75" Pin) 103-16175
$4.75
View Info
Case Backhoe Snap Ring for 2" Pins -- 84158898 | Broken Tractor See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Snap Ring (2" Pins) 84158898
$6.00
View Info
Case Backhoe Washer - 1.5",  10 Gauge Thickness -- U11649 | Broken Tractor See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Washer (1.5" Pins) (10-Gauge / 0.140" Thick) U11649
$4.00
View Info
Case Backhoe Washer 1.5" 14 Gauge -- 495-81292 | Broken Tractor See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Washer (1.5" Pins) (14-Gauge / 0.078" Thick) 495-81292
$3.25
View Info
1.75" Pin Washer for Case Backhoes | Broken Tractor See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 580N, 580 Super N, 590 Turbo, 590 Super L, 590 Super M, 590 Super N Washer, 1.75" Pin Diameter 495-81226
$3.50
View Info
Case Washer 1.75" - 14 Gauge -- 30575 See Details 580B, 580C, 580D, 580 Super E, 580K, 580 Super K, 580L, 580 Super L, 580M, 580 Super M, 590 Turbo, 590 Super L, 590 Super M, etc Washer (1.75" Pins) 30575
$3.25
View Info

Case Backhoe Extendahoe Dipper Arm Parts - Case 590 Super L, 590 Super M

Case Backhoe Extendahoe Dipper Arm Parts - Case 590 Super L
